To decrease engine weight and improve heat transfer, the cylinders have linerless, electroplated aluminum bores
|
|
|
|
|
|
The combustion chamber uses a pentroof/semi-hemi design with a higher compression ratio for more low end torque ad more power throughout the rev range
|
|
|
|
|
|
The alternator, sump, cylinder head, clutch, and cam chain covers are magnesium to cut weight
|
|
|
|
|
|
|
|
The automatic fan is on the left side of the curved aluminum radiator to save space
|
|
|
|
|
|
Includes an LCD temperature gauge
|
|
|
|
|
|
A liquid-cooled oil cooler helps keep the oil cool
|
|
|
|
|
|
|
|
Large ducts for more air pressure, which increases high speed power
|
|
|
|
|
|
The extended opening increases pressure in the system for excellent volumetric efficiency
|
|
|
|
|
|
|
|
|
|
|
|
|
|
A throttle position sensor (TPS) tells the ignition unit how hard the engine is working so it can set the best ignition timing
|
|
|
|
|
|
|
|
A 16-bit central processing unit responds more quickly to engine needs
|
|
|
|
|
|
Never needs adjustment
|
|
|
|
|
|
The rotor has 12 projections to update the processor often
|
|
|
|
|
|
|
|
Four small ignition coils are in the spark plug caps to reduce overall weight, take up less room, and provide strong, consistent spark
|
|
|
|
|
|
|
|
To meet emissions limits and make even more power at the same time, both California and 49-state models have a pre-catalyzer in the pipe leading to the muffler
|
|
|
|
|
|
California models also have a catalyzer in the muffler
|
|
|
|
|
|
|
|
Large 46mm fork tubes are extra rigid to improve handling performance on the street
|
|
|
|
|
|
|
|
Extruded aluminum swingarm is lightweight and rigid
|
|
|
|
|
|
Linage ratios offer smooth and linear suspension response
|
|
|
|
|
|
Upper shock mount is threaded for ride height adjustment
|
|
|
|
|
|
|
|
The six-piston opposed front brake calipers have differential size pistons and aggressive pad material for excellent feel and bite
|
|
|
|
|
|
300mm discus are 5mm thick to stand up to extreme use
|
|
|
|
|
|
|
|
Small overall diameter saves weight
|
|
|
|
|
|
Lightweight, single-piston caliper produces quick, sure stops
|
|
|
|
|
|
|
|
Short wheelbase and steep head angle produce quick, responsive handling
|
|
|
|
|
|
Rigid design assures good handling and durability
|
|
|
|
|
|
|
|
The speedometer includes a coolant temperature gauge, odometer, trip meter, and a clock
|
|
|
|
|
|
The tachometer incorporates a coolant warning light
|
|
|
|
|
|
|
|
The most comfortable Supersport 600 period
|
|
|
|
|
|
The handlebars are an easy reach, a nice flat seat gives comfort for long rides and wide mirrors reveal more than your shoulders
|
|
|
|
|
|
The fairing and windscreen offer an easy ride with great protection from the elements
|
|
|
|
|
|
|
|
Including tank bra, locks, alarm, bike cover |
|
|
