Tuned for high torque output in medium rpm ranges
|
|
|
|
|
|
Compact and lightweight
|
|
|
|
|
|
Stunning appearance to enhance naked design
|
|
|
|
|
|
|
|
Horizontal intake ports improve engine appearance
|
|
|
|
|
|
Fins cast into head improve external appearance
|
|
|
|
|
|
Aluminum die casting cylinder head cover is thin-walled and lightweight yet strong
|
|
|
|
|
|
Designed with large squish area that promotes turbulence to increase flame propagation for superior combustion efficiency
|
|
|
|
|
|
|
|
All-aluminum, closed-deck cylinder block with chrome composite plated cylinders is light, long-wearing and offers excellent heat dispersion
|
|
|
|
|
|
|
|
Quad mufflers of polished stainless steel are heat-treated to an attractive golden color
|
|
|
|
|
|
KLEEN (Kawasaki Low Exhaust Emissions) catalyzer system helps keep the Z1000 environmentally friendly
|
|
|
|
|
|
Honeycomb catalyzer system reduces emissions
|
|
|
|
|
|
|
|
Profiles designed for more low- and mid-range power
|
|
|
|
|
|
Lightweight hollow inlet and exhaust cams each ride in five ball bearings to reduce friction loss
|
|
|
|
|
|
Front cam-chain guide is light, easy to mount and gives more accurate valve timing
|
|
|
|
|
|
|
|
Crowning added to gears improves durability
|
|
|
|
|
|
|
|
Provides excellent engine response and power with less fuel consumption
|
|
|
|
|
|
Compact electronic control unit processes information faster for better engine response
|
|
|
|
|
|
In-tank, electric fuel pump delivers a constant supply of fuel in all riding conditions
|
|
|
|
|
|
38mm throttle bodies with sub throttle valves promote smooth engine operation
|
|
|
|
|
|
|
|
Plug-mounted ignition coils are fitted to suit the new injection system
|
|
|
|
|
|
Compact 32-bit ignition CPU delivers highly accurate information for the DFI® (Digital Fuel Injection) system
|
|
|
|
|
|
|
|
Large-area radiator with electric fan maintains operating temperatures at the proper level
|
|
|
|
|
|
Liquid-cooled oil cooler keeps oil temperatures under control
|
|
|
|
|
|
|
|
Rigid yet lightweight diamond frame of large-diameter thin-walled tubes contributes to responsive handling performance
|
|
|
|
|
|
Engine is mounted as a stressed member for high chassis rigidity
|
|
|
|
|
|
Detachable right front-top engine mount eases maintenance
|
|
|
|
|
|
Steering head uses caged ball bearings for light steering qualities
|
|
|
|
|
|
|
|
Inverted fork with 41mm tubes delivers awesome steering performance
|
|
|
|
|
|
Fork is spring preload and rebound damping adjustable
|
|
|
|
|
|
|
|
Rear shock settings match the rigid chassis
|
|
|
|
|
|
UNI-TRAK® bottom link rear suspensions features a nitrogen gas-charged shock
|
|
|
|
|
|
Shock equipped with piggyback reservoir, spring preload and rebound damping adjustments
|
|
|
|
|
|
|
|
Dual front, semi-floating 300mm discs are gripped by lightweight 4-piston calipers providing impressive braking performance
|
|
|
|
|
|
Rear brake caliper holder designed for low weight and mounts directly to swingarm
|
|
|
|
|
|
|
|
Polished rims contrast nicely with painted hubs and spokes
|
|
|
|
|
|
17-inch radial tires deliver excellent traction
|
|
|
|
|
|
Large diameter front and rear axles are hollow, for high rigidity and low weight
|
|
|
|
|
|
|
|
Seat cowl with LED taillight and swingarm-mounted inner fender give an aggressive, sporty image
|
|
|
|
|
|
Bikini cowl accentuates the bike’s provocative lines
|
|
|
|
|
|
Sleek fuel tank constructed of galvanized steel to resist corrosion
|
|
|
|
|
|
Seating position is very comfortable and allows the rider to mold to the machine
|
|
|
|
|
|
Dual, multi-deflector headlights enhance front-end appearance
|
|
|
|
|
|
|
|
Lightweight, compact instrument cluster features a bar-type LCD tachometer and digital LCD speedometer
|
|
|
|
|
|
Cluster includes digital temp gauge, clock, tripmeter, fuel gauge and a comprehensive range of indicator lamps
|
|
|
|
|
|
|
|
Tamper-resistant ignition switch
|
|
|
|
|
|
Rubber mounted aluminum handlebar dampens engine vibration
|
|
|
|
|
|
Forged side stand is strong and tucks nicely out of the way for ample cornering clearance
|
|
|
|
|
|
Seat utilizes special low-slip surface material for high comfort
|
|
|
|
|
|
Aerodynamic passenger seat cover comes standard |
|
|
