Numerous refinements to the liquid-Engine/Transmission
|
|
|
|
|
|
Head gasket changed from metal gasket to O-rings for improved sealing and more accurate deck height
|
|
|
|
|
|
New intake design features a single port with modified length and angle for improved intake efficiency
|
|
|
|
|
|
Scavenging port exit angle is changed for improved scavenging efficiency, and the crankcase mating area around the scavenge ports has been increased.
Third scavenging port also modified for improved flow
|
|
|
|
|
|
New reed valve angle, air guide and reed block are changed for improved throttle response
|
|
|
|
|
|
Intake air duct is reshaped to suite revised intake manifold
|
|
|
|
|
|
New expansion chamber dimensions and improved construction (changed from four-piece to a three-piece) contributes to improved engine performance
|
|
|
|
|
|
Redesigned piston uses new rings and new piston sealing grooves to prevent ring snagging; stronger pin boss improves durability
|
|
|
|
|
|
Clutch release shaft and lever modified, and release mechanism moved behind generator cover
|
|
|
|
|
|
Shift performance improved by using involute splines on the fifth gear and on the output shaft. A needle bearing added to the shift shaft improves shift feel
|
|
|
|
|
|
New water pump uses new pump gear ratios and a new impellor for increased coolant circulation, plus a new water jacket around the exhaust port eliminates
the need for an external coolant hose
|
|
|
|
|
|
Sprocket cover, governor cover, inner/outer clutch covers, and water pump cover changed to suit new crankcases
|
|
|
|
|
|
Generator cover changed from plastic to magnesium for improved appearance and increased functionality
|
|
|
|
|
|
Revised carburetor settings contribute to improved throttle response, and a new carb holder allows straighter incoming airflow
|
|
|
|
|
|
Radiator core length increased (from 220 to 240 mm) for improved cooling performance
|
|
|
|
|
|
Upgraded ignition system features increased condenser capacity and a generator with a built-in regulator for light weight. Stator shape changed, and
new wiring harness used. Ignition timing changed to suit new power characteristics
|
|
|
|
|
|
New, shorter spark plug eases maintenance and weighs less
|
|
|
|
|
|
New, lightweight ignition coil is more compact
|
|
|
|
|
|
Ignition coil primary terminals feature waterproof couplers for increased reliability
|
|
|
|
|
|
Low-friction throttle barrel also reduces throttle operating friction
|
|
|
|
|
|
|
|
Stainless throttle cable wire with a greater number of thinner strands delivers superb, low-friction throttle operation
|
|
|
|
|
|
Clutch cable outer liner changed from polyethylene to Teflon for reduced friction
|
|
|
|
|
|
Clutch adjuster added to clutch lever perch
|
|
|
|
|
|
New front brake lever has better feel
|
|
|
|
|
|
|
|
Steering rake reduced to 26 degrees to quicken steering response
|
|
|
|
|
|
Footpegs are wider and offer better grip; shorter transverse length means greater cornering clearance
|
|
|
|
|
|
Wider handlebar mounts (increased from 90 to 98 mm) help prevent handlebar bending
|
|
|
|
|
|
New lightweight DID front rims with lightweight spokes and nipples reduce unsprung weight
|
|
|
|
|
|
New cross-section for rear rims also designed for light weight
|
|
|
|
|
|
Light fork and shock mounting bolts and a new rear brake master cylinder with a unitized reservoir and shorter yoke (17.5 mm shorter than '04 KX250)
contribute to light weight
|
|
|
|
|
|
Fork mounting bolt locations changed on the top triple clamp for easier maintenance and stronger mounting
|
|
|
|
|
|
New front brake pad material offers better feel and performance
|
|
|
|
|
|
Chain guide roller now uses two bearings for greater durability
|
|
|
|
|
|
Rear subframe has larger forged upper mounting brackets for improved durability
|
|
|
|
|
|
Fuel tank filler outlet is increased form 37 to 46mm for easier fueling
|
|
|
|
|
|
|
|
Carburetor tuning parts
|
|
|
|
|
|
Ignition rotors with different inertial weights
|
|
|
|
|
|
Larger 14T front sprocket
|
|
|
|
|
|
Spark plugs of varying heat ranges
|
|
|
|
|
|
20-inch front wheel
|
|
|
|
|
|
Solid brake discs
|
|
|
|
|
|
Aluminum and steel rear sprockets
|
|
|
|
|
|
Different fork and shock springs
|
|
|
|
|
|
Steel spoke nipples
|
|
|
|
|
|
Front and rear wheel assemblies |
|
|
