| GENERAL INFORMATION |
| M.S.R.P. |
|
|
$8,999.00
|
|
| Engine |
|
|
Liquid-cooled, DOHC, in-line 3-cylinder |
|
| Displacement |
|
|
675 cc |
|
| Bore x Stroke |
|
|
74 x 52.3 mm |
|
| Compression Ratio |
|
|
12.65:1 |
|
| Torque |
|
|
72 Nm (53 ft.lbs.) @ 11,750 rpm |
|
| Fuel System |
|
|
Multi-point sequential electronic fuel injection with forced air induction |
|
| Horsepower |
|
|
125 ps (123 bhp) @ 12,500 rpm |
|
| Ignition |
|
|
Digital, inductive type, via electronic engine management system |
|
| Transmission |
|
|
6-speed, close ratio |
|
| Clutch |
|
|
Wet, multi-plate |
|
| Final Drive |
|
|
O-ring chain |
|
| Frame |
|
|
Aluminum beam twin spar |
|
| Length |
|
|
79.1 in. (2,010 mm) |
|
| Width |
|
|
26.5 in. (673 mm) handlebars |
|
| Height |
|
|
43.7 in. (1,109 mm) |
|
| Wheelbase |
|
|
54.8 in. (1,392 mm) |
|
| Seat Height |
|
|
32.5 in. (825 mm) |
|
| Dry Weight |
|
|
363 lbs. (165 kg) |
|
| Fuel Capacity |
|
|
4.6 gal. (17.4 l) |
|
| Colors |
|
|
Graphite, Tornado Red, Scorched Yellow |
|
| Suspension |
|
|
Front: 41 mm USD forks with adjustable preload, rebound and compression damping Rear: Monoshock with piggy back reservoir adjustable for preload, rebound and compression damping |
|
| Brakes |
|
|
Front: Twin 308 mm floating discs, 4-piston radial calipers with radial master cylinder Rear: Single 220 mm disc, single piston caliper |
|
| Tires |
|
|
Front: 120/70 ZR 17 Rear: 180/55 ZR 17 |
|
| Rake |
|
|
23.5° |
|
| Trail |
|
|
86.8 mm |
|
|
|
