| GENERAL INFORMATION |
| M.S.R.P. |
|
|
$6,299.00
|
|
| Engine |
|
|
Liquid-cooled, reed valve-inducted, 2-stroke |
|
| Displacement |
|
|
249 cc |
|
| Bore x Stroke |
|
|
66.4 x 72 mm |
|
| Compression Ratio |
|
|
9.2 - 10.9:1 |
|
| Carburetion |
|
|
PWK38S x 1 |
|
| Ignition |
|
|
CDI |
|
| Transmission |
|
|
5-speed |
|
| Clutch |
|
|
Constant mesh/wet, multiple-disc coil spring |
|
| Final Drive |
|
|
Chain |
|
| Length |
|
|
85.7 in. |
|
| Width |
|
|
32.6 in. |
|
| Height |
|
|
51.4 in. |
|
| Wheelbase |
|
|
58.3 in. |
|
| Seat Height |
|
|
39.1 in. |
|
| Ground Clearance |
|
|
15 in. |
|
| Dry Weight |
|
|
211.6 lbs. |
|
| Fuel Capacity |
|
|
2.1 gal. |
|
| Colors |
|
|
Two-tone Team Yamaha Blue / White |
|
| Suspension |
|
|
Front: Telescopic fork, coil spring/oil damper; 11.8 in. travel Rear: Swingarm (link, suspension), coil spring/gas-oil damper; 12.4 in. travel |
|
| Brakes |
|
|
Front: 224 mm hydraulic single disc Rear: 219.8 mm hydraulic single disc |
|
| Tires |
|
|
Front: 80/100-21-51M Rear: 110/90-19-62M |
|
|
|
